H310 LGA 1151 SOCKET DDR4 MOTHERBOARD FOR ALL 1151 PROCESSORS(6th,7th ,8th and 9th Gen as well)

Model

H310 LGA1151 MOTHERBOARD

Processor

Support

  Socket 1151 Core i7/Core i5/Core i3/Pentium/Celeron

Chipset

  H310 Chipset

Memory

Support

  2 * DDR4 2133/2400/2666Mhz

LAN

  Supports Realtek®8105E 100 Mbps

Audio

  Realtek®662 6-channel audio

SATA

  3 * SATA 3.0 port(s),

 Back panel

  1 * VGA port

  1 * HDM1 port
  2 * USB 3.0 Ports

  2 * USB 2.0 Ports
  1 * LAN jack

  3 * flexible audio jacks

 On-Board

 Pinheaders /

 Connectors

  1 * USB 3.0 pinheader
  1 * USB 2.0 pinheader

  1 * F_Audio pinheader

  1 * F_Panel pinheader

  1 * DEBUG pinheader

Slots

  1 *PCI Express x16 3.0  slot   1* M.2 Port

Form Factor

  Micro-ATX (19.4cm X 16.8 cm)
